Genuine spare
OrderNo.: Getriebe_ETZ 125/150
Complete new version with 3,2mm (See pictures)
Layshaft
1x 31-41.012 Layshaft bush
1x 94-02.406 Needle roller bearing 11553
1x 94-37.110 Shim washer 15x0,5
1x 31-46.014 Gear on layshaft (3rd gear)
3x 94-42.374 Circlip 20X1,2 TGL 16363
1x 31-46.012 Layshaft
1x 31-46.016 Sliding gear (3rd gear)
1x 31-46.018 Sprocket - 2nd gear
1x 31-46.023 Check plate
1x 31-46.020 Sliding gear (1st and 2nd gear)
1x 31-46.022 Gear wheel (1st gear)
1x 93-93.106 DKF Groove ball bearing 6201 TNG C3
Clutchshaft
1x 93-93.147 DKF roller bearing 6202 TN C3
1x 31-46.002 Clutchshaft
1x 31-46.004 Drive gear for 4th gear
1x 00-03.052 Circlip 20 TGL 16363 reground
1x 31-46.006 Sliding gear 4th and 5th gear
1x 31-46.039 Sealing ring in mainshaft
1x 31-46.007 Mainshaft with bush
1x 93-93.276 DKF roller bearing 6204 TNG P66
1x 11-47.044 Distance sleeve for chain sprockets
1x 31-46.030 Sprocket on transmission 15 teeth
1x 01-47.008 Locking plate for sprocket
1x 94-73.862 Hex nut M20x1,5
Gear switch
1x 31-47.017 Shift drum
1x 31-47.012 Fork gear selector for 1st and 2nd gear
1x 31-47.014 Fork gear selector 3rd gear
1x 31-47.016 Fork gear selector 4th and 5th gear
1x 31-47.020 Guide bolt
Manufacturer: MZ - VEB Motorradwerk Zschopau, Neue Marienberger Straße 189c, DDR-9360 Zschopau, Telefon: Zschopau 440, Fernschreiber: 07427
