Complete set for engine overhaul MM250/3 - 33 pieces - for ES 250/2 19PS, ETS 250 and TS 250, as we use it in our workshop

Ball bearings:
2x 93-94.381 Ball bearing 6305 TVH C3
2x 10801B Ball bearing 6204 C4
1x 10807B Ball bearing 6302 TN9 C3 polyamide cage
2x 10805 Ball bearing 6203 C3 SKF

Shaft seals:
2x 35088E Shaft seal NJK 30x62x10 - FPM - Viton - brown - with dust lip
1x 10295E Shaft seal NJK 20x30x7 - FPM - Viton - brown - with dust lip
1x 96-59.107 Shaft seal 25x37x7 (double lip)

Gaskets:
1x 28211 Gasket for inspection hole cover
1x 15822 O-ring / round ring 14x2 NBR for rev. counter drive shaft
1x 05-41.087 Gasket for sealing cap on generator side, red
2x 32304-A-M Gasket for inlet manifold
1x 2100000191697 Clutch cover gasket Klingerit
1x 2000000015859 Cylinder base gasket
1x 2100000090174 Gasket for sealing cap on output shafts side

Miscellaneous:
8x 94-68.078 Gasket ring 6x10 TGL 0-7603-CU
1x 94-68.100 Gasket ring A14x18x1,5 - copper DIN 7603
1x 94-68.133 Gasket ring A18x24 for oil drain 7603
1x 10278-00S Spark plug BERU - ISOLATOR ZM14-260 "Spezial"
2x 94-37.746 Locking washer Ø17 TGL 0-432-St
1x 2000000031330 Recuperating spring

Cylinder and crankshaft are not included and can be ordered separately if required!
05-43.101 Crankshaft ES 250/2 19HP, ETS 250 and TS 250
05-42.078 Cylinder ES 250/2 19HP und ETS 250
05-42.091 Cylinder TS 250
CatalogueNo.: 1
